1200LPH Hydraulic Oil Filtration and Dehydration Purifier with PLC Fully Automatic HMI

REXON TYA-20(1200LPH) Hydraulic Oil Filtration and Dehydration Purifier with PLC Fully Automatic HMI is specially designed for purification and regeneration of various industrial hydraulic oil, mechanical oil, gear oil, coolant oil, heat treatment oil, and other low or high viscosity lubrication oils.

By adopting vacuum dehydration, coalescing separation and precision filtration technologies, this hydraulic oil purifier can efficiently remove free water, emulsified water, dissolved gas, particulate contaminants and impurities from contaminated oil. After treatment, the oil cleanliness can reach NAS1638 Grade 6 or better, restoring oil performance and ensuring lubricating systems operate safely and reliably.

Through periodic online or offline oil purification, the hydraulic oil can be reused multiple times, significantly reducing new oil consumption, lowering maintenance costs, and extending the service life of machinery and equipment.

The system is equipped with a fully automatic PLC control system with touch screen HMI, enabling unattended operation, real-time monitoring, and intelligent protection, making it ideal for on-site industrial oil maintenance.

● High-efficiency vacuum dehydration and degassing
● Rapidly removes free water, emulsified water and dissolved gas from high-viscosity lubricating oil.
● Advanced demulsification capability
● Special filter materials and optimised structure effectively break oil-water emulsions thoroughly.
● Coalescing separation + vacuum dehydration technology
● Ensures ultra-low water content and gas content, improving oil stability and performance.
● PLC fully automatic control with HMI touch screen
● Intelligent operation, dynamic display, and automatic running without manual supervision.

● Automatic double infrared liquid level control system

● The newly developed system replaces traditional float or manual valves, improving operational safety and reliability.
● Automatic back-flushing system
● Filters are cleaned automatically during operation, extending filter service life and reducing maintenance.
● Carbon fibre infrared heating system
● Provides fast, uniform and energy-saving oil heating without oil cracking or overheating.
● Robust structure and modern industrial design
● Compact layout, stable performance, long service life, suitable for continuous industrial operation.

● Significantly reduces water content, gas content and impurities in hydraulic oil
● Restores oil viscosity, flash point and lubricating performance
● Improves equipment reliability and reduces unexpected downtime
● Suitable for high-precision hydraulic and lubrication systems
● Helps users achieve oil recycling, energy saving and cost reduction

● In addition, the PLC fully automatic operation system make the machine more intelligent and convenient to operation, such as set machine parameters on the screen, including heating temperature, running time, oil moisture data, fault record, etc. And also can operate the equipment fully automatically through one-touch operation, save manpower and time.

● REXON TYA-20 hydraulic oil filtration machine is widely applied in petroleum, chemical, mining, metallurgy, electric power, transportation, machinery manufacturing, railway etc.
