Explosion-proof Type Coalescing Separation Oil Filter Machine TYB-100 for Light Fuel and Diesel Oil Purification

REXON Explosion-proof Type Coalescing Separation Oil Filter Machine TYB-100 is specially designed to provide efficient oil filtration and oil water separation in hazardous or explosive environments and industries that require high safety and reliability, such as petrochemical, mining, offshore drilling, and power plant operations.

This TYB-100 oil filter machine adopts high efficiency demulsification and dehydration coalescence-separation filters and integrates a fine filter into one machine body, which can offer a super high efficiency water removing ability than other normal types of filters. This oil filter machine can quickly separate large water from oil, even contains half water in oil.

1. TYB-100 oil purifier adopts special coalescence-separation filters, which offer much higher water removal efficiency than other types of purifiers.

2. Without vacuum heating and high-speed centrifugation.

3. Reduce water content to less than 100 PPM or less.

4. Clean oil and achieve the oil cleanness of NAS grade 6 or better.

5. As no heating is needed, the additives in the oil are well protected from degradation or deterioration.

6. Movable design, easy to move and operate in the workshop.

1. TYB-100 coalescing separation oil filter machine is equipped with a certified explosion-proof motor and explosion-proof control cabinet, explosion-proof sensors, and explosion-proof cables, which guarantee safe operation in areas with flammable gas, vapour, or dust.
2. It is equipped with a PLC fully automatic system and a 10-inch colourful touch screen. Once the parameters are set in the program, the equipment can run automatically.

3. In addition, if there are any abnormalities, such as system overpressure, filter element being clogged, etc., the machine will issue an alarm and automatically shut down, and the PLC screen will prompt specific errors.

4. Fully automatic water discharging. This purifier is controlled by PLC system. Once the separated water reaches the set level, the machine will discharge water from the machine's water storage tank fully automatically.
